General
SAK/JXB series combined terminal blocks mainly use Germany Woodmeler’s connection technology, and designed and made at home. Technology targets conforms to the standard or IEC 60947-1, IEC 60947-7-1, GB14048.1. However, JXB is only for mountin gon , increase the high current terminal series.
Characteristics
1、Reasonable installing design, strong versatility, SAK type can be mounted on the guide of Gand TH type.
2、small volume, full specification, series JXB’s big current terminal use reinforced accessories to install steel pressing-wire frame and wire diversion board technology in order to guaranjtee the contact reliable.
3、the stand uses creamed-yellow and grey color, the connecting-grounk pedestal uses yellow and green color with moer modern sense.
Explain |
| (1)end voltage/thick1.5mm, grey or cream-color |
 |
| (2)Center connection piece:10 position, can be divided into 2, 3 or 4position. |
 |
| (3)Universal end fixed piece |
 |
| (4) Printing number continuous mark stripe. |
 |
SAK SERIES COMBINED TERMINAL BLOCKS
JXB SERIES COMBINED TERMINAL BLOCKS(GREY) |
SAK 2.5EN
JXB 2.5/35 |
SAK 4EN
JXB 4/35 |
SAK 6EN
JXB 6/35 |
SAK 10EN
JXB 10/35 |
| 0.2-2.5mm2 |
0.2-4mm2 |
0.2-6mm2 |
0.2-10mm2 |
| Current:24A |
Voltage::800V | |
| Current:32A |
Voltage::800V | |
| Current:41A |
Voltage::800V | |
| Current:57A |
Voltage::800V | |
| 2.5EN Q2位,3位,10位 |
(2.5Q2-10) | |
| 2.5EN Q2位,3位,10位 |
(4ENQ2-10) | |
| 6EN Q2位,3位,10位 |
(6ENQ2-10) | |
| 10EN Q2位,3位,10位 |
(10ENQ2-10) | |
|
|
|
|
|
|
|
|
|
|
SAK 16EN
JXB 16/35灰色 |
SAK 35EN
JXB 35/35灰色 |
SAK 70EN
JXB 70/35灰色 |
SAK RD
JXB RD |
| 0.5-16mm2 |
10-35mm2 |
25-70mm2 |
0.2-4mm2 |
| Current:76A |
Voltage::800V | |
| Current:125A |
Voltage::800V | |
| Current:192A |
Voltage::800V | |
| Current:6.3A |
Voltage::500V | |
| 16EN Q2位,3位,10位 |
(16ENQ2-10) | |
| 35EN Q2位,3位,10位 |
(35ENQ2-10) | |
|
| 10EN Q2位,3位,10位 |
(10Q2-10) | |
|
|
|
|
|
|
|
|
|
|
DK 4Q/35
JXB-4/35S1灰色 |
SAK WTK
JXB W16/1 |
| 0.5-16mm2 |
0.2-4mm2 |
| Current:76A |
Voltage::800V | |
| Current:41A |
Voltage::400V | |
| 16EN Q2位,3位,10位 |
(16ENQ2-10) | |
| WTK2-10位于 2位,3位，4位,10位 |
(WTKQ2-10位) | |
|
|
|
|
|
| |
| SAK SERIES COMBINED TERMINAL BLOCKS |
| SAK SERIES TERMINALS ATTALHMENT |
|
